NON-WALK-IN Rescue


What. Where. How. Covered.

Overview

Pierce® Non-Walk-In Heavy Duty Rescues carve out every
free inch of storage space in the lower body and atop the
roof. Nothing goes to waste. Plus, you get maximum support through our exclusive underslung body support system.

• Maximum custom storage for any major rescue system.
• Exterior compartment weight evenly distributed to frame.
• Custom fabricated shelves and trays.


Specifications

Body Material

Aluminum or Stainless Steel

Body Lengths

14' Single Axle to 26' Tandem Axle

Body Heights

90" to 106"

Body Widths

96" w/ 28" Deep Side Compartments or 100" w/ 30" Deep Side Compartments

Doors

Roll or Traditional Hinged Style

Roof Construction

Double Wall Hatch Construction w/ Diamond Plate Walking Surfaces

Roof Access

Traditional Side Ladder, Built-in Stair or Center Walkway Pull-down Stair

Body Support

Full Front and Rear Underslung Frame Mounted Support Platforms

Body Construction

Structural Tube Framing and Formed Sheet Metal Body Panels Throughout

Body Structural Warranty

15 Years

Compartment Storage

Pierce® Designed Extruded Pull-out Adjustable Trays, Slide-out Tilt Trays, Tool Boards and Custom Equipment Storage Racks

Body

Click to toggle popover

Compartment Storage

Select from various door styles, trays, shelves, brackets and tool boards to efficiently store and access firefighting equipment

Click to toggle popover

Body Construction

Side sheets are reinforced with extruded 2”x2” tubes over the body length, increasing rigidity and durability

Click to toggle popover

Roof Access Options

Fixed and slide-out ladders and staircases available

Click to toggle popover

Roof Construction

Reinforced walkway and hatch compartment floors are covered with slip-resistant aluminum treadplate

Click to toggle popover

Integral Roof Storage Compartments

Feature double-wall construction; the compartment wall is buffered from the side sheet by 2” X 2” tubes

Click to toggle popover

Exclusive Underslung Body Support System

Mounted to the chassis frame rails, the system supports all exterior compartments and evenly distributes weight to the frame

Click to toggle popover

Center Of Body Mounted On Frame Rails

Evenly distributing compartment loading to chassis frame rails

Click to toggle popover

Fire Suppression

Available with pumps ranging from 250 gpm-1500 gpm and water tank sizes up to 500 gallons

Click to toggle popover

Systems Design

Comprehensive engineering design solutions for breathing air cascade, hydraulic tool and low pressure tool air systems

Options Showcase

Sacramento Metropolitan Fire District - Rescue

Sacramento Metropolitan Fire District - Rescue

Delivery Date: April 28, 2017
Job Number: 29817
Sales Organization: Golden State Fire Apparatus, Inc.
