PUC™


The Pierce Ultimate Configuration.

Easier to use. Easier to stay safer. Easier to store more. Easier to service. Easier to maneuver.

Overview

The Pierce® PUC™ is the first modern tilt cab emergency response vehicle designed specifically for the response duties of today’s fire services. The PUC eliminates the pumphouse so you can build your apparatus around your needs and not the pump. It minimizes vehicular space used for fire suppression and maximizes space for equipment while still providing big pump, foam and CAFS capabilities.

PUC removes the need to build the entire body around the pump and the pumphouse. And it’s the first apparatus that offers the most complete single-source build, from the chassis and body, right down to the pump. PUC is available on pumpers, rescue pumpers, tankers and aerials.




Features

The first modern tilt cab emergency vehicle designed specifically for the response of today’s fire services, offering the most complete single-source build, from the chassis and body, right down to the pump.

Click to toggle popover

Electro-Magnetic Clutch

Allows for a two-step pump process; (1) Simply pull the parking break in the cab, (2) Push a switch and your pump is engaged

Click to toggle popover

Chest Height Crosslays

The lower positioning makes it easier to deploy hose

Click to toggle popover

Adjacent Pump Panel Position

Pump operator is next to the hose connections instead of over them

Click to toggle popover

Easier To Service

Its convenient location allows for all maintenance to be completed above the frame rails, no more working from under the truck on your back

Configurations

  • Pierce-PUC-Pumper-BodyConfiguration.jpg

    PUC Pumper

  • Pierce-PUC-Tanker-BodyConfiguration.jpg

    PUC Tanker

  • Pierce-PUC-Aerial-BodyConfiguration.jpg

    PUC Aerial

  • Pierce-PUC-Rescue-BodyConfiguration.jpg

    PUC Heavy Duty Rescue

Pump Panel

The 1500 gpm pump (rated for draft) weighs 30% less than most existing pumps on the market and comes with a 6-year standard warranty.

We enclosed the pump operators panel on the side mount to keep it clean of grime, grit, and moisture. The next generation Control Zone™ pump panel is designed to fit the way you work with:

•    Large lever control handles that lock to prevent valve creep under pressure

•    Multi-functional pressure governor

•    Extra-large engine RPM display

•    Fuel level monitoring

•    Pump prognostics


Specifications

Chassis Choices

Velocity®, Impel®, Enforcer™, Quantum®, Dash® CF, Arrow XT™

Tank Capacities

Up to 1500 gallons / lifetime warranty

Electrical System

Color coded every 3"/harness loom-protected

Body Warranty

10-yr structural

Stainless Steel Piping Warranty

6-yr

Pump Warranty

6-yr

Wheelbase

162" - 212" (depending on body size and chassis)

Pump and Roll

Standard

Compartment Space

150 - 500 cubic feet (depending on body size and chassis)

Compartment Load Rating

Up to 800 pounds each

Body Material

Aluminum standard, 304L stainless steel option

Body Support Substructure

Lateral frame extensions

Pump Panel

Pierce Control Zone™

Plumbing

Stainless steel 10-yr warranty

Pump Range

1250 - 1500 gpm


Compartment Storage

The PUC™ features 26" deep compartments and up to 500 cubic feet of big, clean, uncluttered storage space with covered raceways, recessed shelf tracks and bright strip lighting that reduces shelving shadows and gives excellent night-time visibility.

PUC also features a long list of options including:

  • 500 lb sliding floor trays
  • Dividers
  • Tilt-out shelves
  • Swining tool boards
  • Reel mountings

You can configure any option with the roomy Pierce® “jump-off” compartment near the rear of the passenger side cab door for EMS, rescue or turnout gear or whatever you decide to store.

Options Showcase

Livonia Fire and Rescue - Pumper

Livonia Fire and Rescue - Pumper

Delivery Date: February 1, 2017
Job Number: 30122-01-02
Sales Organization: Halt Fire, Inc.

Learn More
