Enforcer™

Pierce Enforcer Custom Chassis

The legacy grows.

ENFORCER BROCHURE

Overview

Proven reliability returns. The Pierce Enforcer chassis is more capable than ever. With TAK-4® independent front suspension, your choice of two powerful engines and Pierce's exclusive Command Zone™ multiplexed electrical system, the Enforcer performs like never before.

Plus you can take advantage of significant improvements in visibility, space, ergonomics, and serviceability.

Enforcer 360° Interior Tour

Pierce Enforcer Custom Chassis Cab

Visibility & Space

  • Exceptional visibility is achieved through a large, bonded, single-piece, wrap-around windshield.
  • The smaller engine tunnel is lower & more contoured for increased occupant space, particularly up front for the driver & officer.
  • The forward roof design offers a cathedral ceiling feel with increased frontal visibility & more configurable space.

Ergonomics

  • Exterior door handles are functionally designed for a firefighter's gloved hand.
  • The steps are lower to the ground & offset to function like a stair step, making it easier for firefighters to enter & exit the cab.
  • The console & metal overhead switch panel are ergonomically designed for maximum convenience & comfort, keeping all of the gauges & switches within easy reach of the driver.

Serviceablity

  • Easy access to the defroster & wiper motors through removable officer-side panels.
  • Power distribution relocation provides more interior space & fewer harnesses in the frame & up through the cab for easier servicing.
  • Built-in wire raceways throughout the cab reduce the chance of wire chafing & make it easier to service or add cab harnesses & wiring.







Maneuverability

  • Maximum 50-degree cramp angle & 15-degree angle of approach for improved maneuverability in those tight areas & challenging situations.

Specifications

Design

Cab DimensionsLength 60", 70" or 84" / Width 96" Cab Roof StyleFlat or raised (10" or 24")
DoorsBarrier or full height Electrical SystemHard Wired or Command Zone™
Frame Rail10-1/4" Front Axle SuspensionLeaf or TAK-4®
Frontal Air BagsDefault Rear Axle SuspensionLeaf, rubber, air, TAK-4® or TAK-4 T3™; single or tandem
Seating Capacity8 Side Roll ProtectionDefault

Performance

Alternator270 - 430 amp Cramp Angle (maximum)50°
EngineCummins L9 or Detroit Diesel DD13 Engine Horsepower370 - 525 hp
Front GAWR (maximum)24,000 lb Rear GAWR (maximum)48,000 lb
TransmissionAllison 3,000 EVS, 4,000 EVS, or 4,500 EVS

Proprietary Options

Aerial Snozzle®
Electrical Command Zone™
Pump PUC™
Suspension TAK-4® Independent Front Suspension
TAK-4® Independent Rear Suspension

Cab tilt

An increased cab tilt angle improves access to the chassis components under the cab.

Oversized door handles

Exterior door handles are functionally designed for a firefighter's gloved hand.

Large front door

Side visibility is improved by a slightly larger front door and a narrower A-pillar.

Forward roof design

The forward roof design offers a cathedral ceiling feel with increased frontal visibility & more configurable space.

Low, offset cab steps

The steps are lower to the ground and offset to function like a stair step, making it easier for firefighters to enter and exit the cab.

Single front windshield

Exceptional visibility is achieved through a large, bonded, single-piece, wrap-around windshield.

New Deliveries

Palos Fire Protection District - Pumper

Palos Fire Protection District - Pumper

Delivery Date: June 26, 2019
Job Number: 33305
Sales Organization: Global Emergency Products

Learn More View All Deliveries
