Electric Fire Truck Reference Guide

A red electric fire truck has its warning lights on at dusk with a blue evening sky in the background.

Overview

The future of fire apparatus is electric. Electric fire trucks offer municipalities the opportunity to achieve zero emissions with no compromise on safety, response or operational effectiveness.

This electric fire truck reference guide covers all of the information a fire department needs to understand about electric vehicles and how they integrate into an existing fleet.

Cover image of the Pierce Electric Fire Truck Guide featuring a red electric fire truck.

Download this Guide

The future of firefighting is electric! Use this free guide as a tool to help your fire department and municipality understand electric fire truck features, fleet integration, service and more!

Download your guide

What is an Electric Fire Truck?

An electric fire truck, also referred to as an electric fire engine, is a fire truck powered by electric power.

There are several electric fire trucks on the market today, each with its own list of attributes and unique design and manufacturing qualities. The common factor between all brands is that while the majority of truck operations are fueled by electric energy, they all have a backup source of power. Backup systems ensure lifesaving efforts are not delayed based on depletion of charge or lack of power supply.

Types of Electric Fire Trucks

A computer rendering shows the side view of an electric fire truck isolated on a white background with the battery highlighted blue and labeled in black.As demand for electric vehicles increases, a few manufacturers have introduced considerably different concepts in recent years. The types of electric fire trucks fall within two main categories, listed below.

Parallel-electric drive train fire apparatus operate independently in either all-electric or internal combustion engine modes. The benefit of choosing a parallel-electric drive train fire truck with an internal combustion engine (ICE) is that the chassis operates under electric power in all normal operational situations and leverages the internal combustion engine only for backup power in extended emergency operations. When the fire truck is under these extended conditions, it operates with the engine coupled directly to the drive line with reduced complexity and added resiliency.

Range-extended electric vehicles run on battery power and utilize a generator or engine as backup power. Once the battery’s state of charge drops below a specified threshold, the generator or engine engages and the battery continues to power all operations while the ICE powers the batteries. Unlike the parallel-electric drive train fire truck which bypasses the batteries completely, a range-extended vehicle continues to use the battery at all times.

What are the Benefits of an Electric Fire Truck?

A red electric fire truck driving down the road has a blue image overlay that shows the battery at work.There are many inherent benefits that come with the use of an electric fire truck.

  • Reduced emissions. An electric fire truck substantially reduces overall emissions and offers a sustainable solution to reduce a fire department’s carbon footprint. An electric fire truck with an internal combustion engine to power the parallel drive line is more resilient than a range-extender, which relies on the batteries to transition the electrical energy back to the drive line.
  • Meeting new environmental standards. Across the world, states, provinces, cities and towns are striving to achieve 100% clean, renewable energy. Electric vehicles are an essential step to reach these goals, and many leaders recognize the value of investing in electric fire trucks to lead the charge.
  • Minimize fuel use and fuel cost. With an electric-powered fire truck, the overall use and costs of diesel fuel diminish, saving municipalities money while supporting their environmental goals.
  • Less noise. An all-electric fire truck offers improved communication in the cab, reduced on-scene noise and improved communication for the firefighters, and less stress on others involved in or who are receiving the focus of the emergency response.
  • Improved firefighter safety. The reduction in carbon emissions means firefighters will have less exposure to toxins in the air at the fire station, on scene and at combustion fueling centers. With less fuel use, firefighters will also have less direct contact exposure. This directly supports the CARE Initiative, a program designed to raise awareness about carcinogen exposure and encourage more safety precautions for firefighters to reduce cancer risk.

How is Zero-Emissions Achieved?

electric-fire-truck-electrical-mechanical-infinitely-variable-transmissionPierce® Volterra™ electric fire truck technology consists of an Oshkosh patented parallel-electric drive train featuring an electro-mechanical infinitely variable transmission (EMIVT) which allows zero-emissions operation when powered by the integrated onboard batteries.

The integrated electric motors in the electro-mechanical infinitely variable transmission are always providing the output to the driven components, whether it’s the pump or the drive axle.

Because the EMIVT can also be coupled to the internal combustion engine, it will always provide continuous and uninterrupted power to the pumping system or drive system.

Learn more about fire truck electrification modes here.



Why is There Growing Demand for Electric Fire Trucks?

An interior image of an electric fire truck cab shows the front windshield, driver and passenger going about day-to-day operations. From demanding environmental goals to reduced emissions, a smaller carbon footprint and cost savings, there are many reasons why fire departments across the world are seeking electric fire trucks.

Here’s a look at some of the reasons why the demand for electric fire trucks is growing.

Changing regulations and legislation. With each passing year, more and more local and state governments develop clean vehicle policies to reduce greenhouse gasses, improve air quality and increase sustainability. In the United States, over 170 cities, more than ten counties and eight states have goals in place to power their communities with 100% clean, renewable energy. Electric fire trucks provide municipalities with a sustainable solution to help meet their local and state legislative requirements.

Environmental initiatives. Currently, emissions from vehicles contribute to about one-third of all U.S. air pollution. Tailpipe emissions have detrimental effects on the health, safety and welfare of community members. More municipalities are taking the initiative to address constituents' concerns about the environment. By prioritizing environmental programs and choosing electric vehicles, municipalities are leading by example for the community at large. Choosing electric vehicles for municipal fleets sets a standard for excellence with a focus on improving overall community health. Municipal fleets operate routes that are aligned with range. Buses, refuse, delivery and fire apparatus all leave and return to a common site on a daily or frequent cycle. This allows them to leverage infrastructure which is more commonly available in urban environments.

Cost Savings. Fire trucks represent a significant source of fuel consumption and can ultimately cause a detrimental environmental impact. The adoption of electric fleet vehicles can help significantly cut both fuel costs and the negative impacts of fuel consumption. In addition to saving on fuel costs, municipalities and fleet managers can anticipate savings on preventive maintenance, ongoing engine repairs and down time spent on re-fueling.

How Do You Charge an Electric Fire Truck?

A female firefighter plugs an electric fire truck into the overhead power source in a fire station.An all-electric fire truck with an internal combustion engine charges much like a typical home electric vehicle connected to an electric power source.

Choosing a zero-emission electric vehicle requires solutions to recharge, whether it’s at the fire station, or other municipal or community settings.

Fire departments are finding success with the installation of charging solutions at the station. When you partner with Pierce, charging solutions are easier than you may think to install. Pierce and its network of trusted energy partners manage all aspects of planning, charging installation and ongoing maintenance and support.

The integration of overhead charging stations for electric vehicles matches the infrastructure of most existing firehouses and is beneficial because it doesn’t take up valuable floor space.

The charging process itself is simple. Plug in the power and in most scenarios, an electric fire truck can regain full charge in one hour. Depending on the state of charge, normal charging times are often quite less.

Learn more about the process in this blog post: Electric Fire Truck Charging Infrastructure Overview

Does Emergency Response Change with an Electric Vehicle?

electric-fire-A red electric fire truck drives under a cement overpass with a blurred background.truck-emergency-responseElectric fire truck manufacturers are committed to the safety of firefighters and their lifesaving work. As such, electric fire trucks are designed to maintain the high level of operational standards firefighters demand with no compromises.

Pierce electric fire trucks offer the same reliability and functionality as all traditional apparatus. This includes optimal:

  • Driveability. The truck feels and looks like a traditional vehicle. As a result, there is a significant improvement in firehouse operational efficiency; system controls and components can be in the same locations across an entire fleet and training can be streamlined.
  • Operability. Pierce Volterra electric vehicles offer the same maneuverability and operability as other available Pierce apparatus because the design and manufacturing components remain consistent across all chassis and vehicle types. Pumphouse layout and configurations, and body and compartment space configurations remain unchanged between traditional apparatus and Volterra apparatus configurations. Consistent configurations with existing fleet vehicles improve operational efficiently and truck familiarity for operators.

To learn more about integrating an electric fire truck into your fleet and how Pierce electric fire trucks are serving local communities now, reach out to your local dealer.

How Does Cold and Warm Weather Affect Electric Fire Truck Performance?

Electric fire engines, regardless of weather, must maintain reliable and responsive performance.

The Pierce Volterra electric fire truck is equipped with a sophisticated thermal management system to counteract the adverse effects of temperature on the battery.

A battery thermal management, like the system on the Pierce Volterra, supports immediate operational readiness and contributes to extending battery life expectancy.

Learn more about this process and see real-life examples in this blog article: Electric Fire Trucks in Cold Weather: Facts, Challenges and Examples

How Effective Is Pump Performance on Electric Vehicles?

Fire departments rely on mission-ready trucks ready at all times to support emergency response demands. So how do electric fire trucks manage prolonged fire events requiring pump operations?

It depends on the type of vehicle and the architecture of the drivetrain.

Parallel-electric Drivetrain Fire Apparatus

A fire apparatus with a parallel-electric drivetrain, like the Pierce Volterra, operates in either all-electric mode or internal combustion mode.

  • The batteries are designed to power all truck operations as long as the battery level is running above the lowest threshold.
  • Once below the threshold, the ICE automatically kicks in and maintains the rated power to the vehicle.

Pierce Volterra can power all truck operations at full capacity, including the ability to drive the vehicle or pump up to 2000 gpm at a continuous rate of pressure and performance in both all-electric and internal combustion mode.

Range-extended Series-Electric Drivetrain Fire Apparatus

In contrast to a parallel-electric drivetrain, a range-extended series-electric drivetrain vehicle uses battery power until the batteries are depleted and then uses an engine driven generator to continue to power truck operations through the battery.

In certain series-electric configurations, the batteries are involved in the vehicle’s ability to provide power, and once the batteries become depleted, or faulted, the back-up power source may not be able to supply enough power through the batteries to manage pump operations.

Additionally, some electric fire truck systems may not be sized large enough to meet the power requirements of a 2000 gpm pump, let alone be adequate to first charge the batteries and then run the pump at the rated capacity. A range-extended series-electric vehicle with depleted batteries may not even be able to move until the batteries are recharged, and charging may not occur while pumping.

Interested in diving deep into this topic? Review this article: Q+A: How Does Electric Fire Truck and Pump Performance Compare to a Traditional Truck and Pump?

Electric Fire Truck Service and Maintenance

A touchscreen inside an electric fire truck shows the battery level status.Electric fire truck service and maintenance largely follow traditional fire apparatus day-to-day service and maintenance. However, the added bonus of an electric fire truck is that you should expect less frequent engine and engine-related component maintenance because they are not used as often, therefore the intervals occur less frequently. Other systems, like braking, may also see less frequent repairs (depending on driving conditions) than a traditional apparatus due to regenerative braking from the electric drive line.

With any electric fire truck, battery and high-voltage component maintenance will be required. In these cases, trained maintenance technicians will require high-voltage tools to complete service.

Use-based maintenance, like oil changes, are completed following regular engine protocols. However, because the engine is used less frequently, standardized maintenance needs should decrease as well as the overall cost of preventative maintenance. Most importantly, the vehicle will not be out of service as often because of the longer intervals between standardized maintenance.

In terms of servicing charging infrastructure, it’s actually quite simple! There is not a lot of necessary maintenance because there are not a lot of moving parts. Following basic intervals for inspection set by the charging solutions provider will ensure the infrastructure maintains its ready state.

Can Firefighters Perform Routine Maintenance on Trucks with High-voltage Power?

High voltage systems on electric fire trucks are designed to be safe under normal operating conditions. However, the placement of high-voltage elements on fire apparatus can significantly affect firefighter functionality, serviceability and overall safety.

The Pierce Volterra electric fire truck consolidates and isolates electrical components to a single area on the fire truck body behind the cab. The truck was specifically designed to keep all electrical elements in one place so firefighters could easily manage operations and maintenance with confidence they will not inadvertently encounter high-voltage wiring or components.

As fire departments consider adding an electric fire truck to their fleet, it’s important to ask electric fire truck manufacturers about high-voltage component and wiring placement because it can significantly impact operation and maintenance.

To learn more about how firefighters can effectively manage electric fire truck high voltage components and key considerations for placement, review this recent article: Q+A: Electric Fire Truck High Voltage Overview

What Happens If Electric Fire Truck Batteries Are Damaged?

In the unlikely event that electric fire truck batteries are damaged, how the truck maintains operational capacity is again dependent on the type of truck.

  • If a battery cell is damaged or if the battery has a fault on a parallel-electric drivetrain fire truck like Pierce Volterra, the ICE is sized and connected as a full-power solution to manage rated operations until the battery issue can be addressed.
  • A range-extended series-electric drivetrain may have to stop operation or operate with restricted performance capabilities until the battery issue can be addressed.

A damaged or faulted battery which renders a truck unusable is not a reliable option for fire departments.

How Does a Fire Department Set Up for an Electric Fire Truck?

An electric vehicle charging station high voltage cabinet sits inside a fire station.When you choose to purchase a Pierce Volterra electric fire truck, you’re not just investing in a truck; you're investing in a complete electric vehicle solution. Understanding how an electric fire truck can fit in your station, on your power grid and into your service model are all items that Pierce and its energy partners help manage on your behalf.

Pierce representatives align experts to support your needs so you can focus on your daily work and not on the technical details of your new apparatus. This includes:

  • Assessing your firehouse to understand the electric fire truck and charging infrastructure requirements.
  • Working with your local utility to establish the right sized source and coordinate any necessary updates to support the charging infrastructure.
  • A seamless installation process that allows fire departments to work with one team from concept to commissioning with transparent and open communication.

To appropriately power the Pierce Volterra™ platform of electric vehicles, a fire station will need enough 480-volt three-phase power to support the charging infrastructure. This is standard for any commercial power requirements. If 480-volt power is not available, this power requirement can be accomplished with a step-up transformer.

While smaller charging units may be used to provide support, they will limit the ability for fast charge recovery and negatively impact response-readiness.

Full station energy planning is the optimal choice because it considers both short and long-term energy goals and provides solutions to ensure departments are aligned with operational expenses and budgeting. Starting with an EV charging solution that can support future growth and long-term energy goals across all specialty vehicles is important and is often a better long-term investment.

Integrating the necessary electrification components in a fire station and getting an electric fire truck up and running is a straightforward and seamless process. Learn more about this six-step process in this blog post.

How Does an Electric Vehicle Fit Into My Current Fire Truck Fleet?

A group of firefighters in station gear stand outside in front of a red electric fire truck as one firefighter leads a training session. The process of integrating an electric fire truck into your department fleet can run as seamlessly as adding any other type of apparatus—ultimately, it comes down to planning and power.

Adding an electric fire truck to a fleet doesn’t necessarily translate into more planning steps, but to promote efficiency over time, it may involve additional discussions around future energy objectives. For example, a municipality may look to add an electric ambulance or other electric utility vehicles to the fleet, and thinking through future goals can help set up the department for success.

Look at the needs of your fire departments, your future energy-saving goals and your local or state legislature to give you a timeframe regarding when to integrate electrification technology.

The process of planning for, selecting, manufacturing and integrating any new fire truck into your fleet takes time. Adding an electric fire engine is no different. You can count on Pierce to help manage the process and support your fire truck needs before, during and after you receive your new electric fire truck and provide service support for the lifespan of the apparatus.

Electric Fire Truck Design

A computer rendering of an electric fire truck highlights the electrification components with a blue color and black labels.Fire trucks come in all shapes and sizes and electric fire trucks are no different.

The Pierce Volterra™ platform of electric vehicles is designed to look like a traditional North American fire truck and match the style and operational configuration of the existing trucks in your fleet.

Each truck is equipped with the Oshkosh Patented Parallel-Electric Drive Train, which includes:

  • Electro-mechanical infinitely variable transmission (EMIVT)
  • Integrated onboard batteries
  • Internal combustion engine (ICE) for continuous and uninterrupted power to the pumping system or drive system

The parallel-electric drivetrain featuring an EMIVT allows zero-emissions operation when powered by the integrated onboard batteries.

The electric fire truck operates independently in either the all-electric or internal combustion engine modes; the EMIVT can leverage either source of power to provide uninterrupted performance in extended emergency operations. Moreover, this simplified solution allows traditional vehicle accessories to be powered by the EMIVT as well.

Internal combustion engine engagement is automated with seamless transition after batteries have been depleted, and overall, EMIVT's parallel electric drive is more resilient than a range extender.

Standardized Pierce pumping configurations, up to 2000 gpm, are driven through the EMIVT and are powered by either the integrated onboard batteries or the internal combustion engine. The driveline allows for zero-emissions during quick attack responses, with the ability to transition seamlessly to internal combustion power for extended pumping operations.

Learn more about the design details of the electric fire truck now

Electric Fire Trucks on the Road Today

The Madison, Wisconsin red electric fire truck is parked outside fire station number 8. City of Madison Fire Department

The first Pierce Volterra zero-emissions pumper was placed in service in 2021 with the City of Madison Fire Department, making this the first electric fire truck in service in North America. The Volterra pumper is serving front line duty at Station 8, the City of Madison’s busiest fire station. The department is made up of 14 fire stations serving an area of nearly 100 square miles and a population of over 250,000.

“The City of Madison is committed to many sustainability initiatives allowing us to meet our needs without compromising those of future generations,” said former Chief Davis. “Pierce’s Volterra electric pumper allows us to keep an environmentally-conscious focus on reducing emissions while maintaining our traditional pumper configuration without impacting our operational procedures. We are eager to lead change by responsibly supporting our environment together with achieving our critical daily missions.”

Portland Fire and Rescue

A close-up image shows the diver side panel of the Portland Fire Rescue electric fire truck with the emblem. Portland Fire and Rescue is made up of 31 fire stations serving an area of 151 square miles and a population of over 650,000. Fire Chief Sara Boone considers the addition of Pierce’s Volterra electric pumper a significant contribution to the city’s sustainability efforts.

“In 2016, the city achieved its 2030 Environmental Performance Objective for Fleet when 35-percent of fuel use came from renewable sources,” stated Chief Boone. “Fleet electrification is expected to be a primary driver of carbon emissions reduction from city vehicles, and exploring the role of the Pierce Volterra electric pumper within our fire apparatus fleet is a big step toward reaching our future goals.”

Learn more and see renderings for the Portland Fire & Rescue electric pumper fire truck now.

Gilbert Fire and Rescue Department

A red electric fire truck driving on the road with blue sky and white clouds in the background.

Gilbert Fire and Rescue Department in Arizona has placed a Pierce Volterra into service at the department's busiest station, Station No. 2. The Gilbert Fire and Rescue Department is led by Fire Chief Rob Duggan and is made up of 11 fire stations and 276 members.

“We are excited for the opportunity to partner with Pierce to add the Volterra electric pumper to our fire fleet because this partnership reflects and exemplifies Gilbert’s mission to anticipate and recognize the current and future needs of all who reside in the areas we serve,” said Chief Duggan. “An additional attribute critical to our department is the Volterra pumper will allow us the benefit of exploring ways to eliminate cancer-causing diesel exhaust particles from our fire stations.”

Learn more and see renderings for the Gilbert Fire and Rescue electric pumper fire truck now.
